Name: DHN-72X16/DG(MM)-555-570W
Brand: Landmark Solar
Price: 170.50 GBP
Availability: OutOfStock

£170.50

High tech coatings guarantee color stability 30 years

No.of Cells	144 (6×24)	Cable(Including connector) Junction Box	4.0mm2, 300/200mm in length,
Weight	31.2kg	Cable(Including connector) Junction Box	Length can be customized
Cells Type	N-type 182×91mm	Glass	2.0mm High Transmission, Antireﬂection Coating
Dimension (L×W×T)	2278×1134×30mm	Junction Box	IP68, 3 Bypass Diodes
Packing	36pcs/Pallet, 720pcs/40HQ	Connector	MC4 Compatible

Module Type	DHN-72X16/DG(MM)
Test conditions	STC	NOCT	STC	NOCT	STC	NOCT	STC	NOCT
Maximum Power (Pmax/W)	555	417	560	421	565	425	570	429
Open-circuit Voltage (Voc/V)	51.86	49.27	51.89	49.30	51.93	49.26	51.96	49.37
Maximum Power Voltage (Vmp/V)	43.36	41.19	43.39	41.23	43.43	41.26	43.46	41.29
Short-circuit Current (Isc/A)	14.27	11.52	14.35	11.59	14.41	11.63	14.47	11.68
Maximum Power Current (Imp/A)	12.80	10.13	12.90	10.22	13.01	10.30	13.11	10.38
Module Efﬁciency (STC)	21.48%		21.68%		21.87%		22.07%
Refer Bifacial Factor	80±5%
STC-Standard Test Environment: Irradiance 1000W/m2, Cell temperature 25°C, Spectrum AM1.5 NOCT-Standard Test Environment: Irradiance 800W/m2, Ambient temperature 20°C, Spectrum AM1.5, Wind speed 1m/s

Operating Parameters		Temperature Coefﬁcient
Maximum System Voltage	1500V DC	Temperature Coefﬁcient of Isc (αIsc)	0.046%/°C
Operating Temperature	-40 ~ +85°C	Temperature Coefﬁcient of Voc (βVoc)	-0.25%/°C
Maximum Series Fuse Rating	30A	Temperature Coefﬁcient of Pmax (γPmp)	-0.29%/°C
Nominal Operating Cell Temperature	45°C±2°C	Snow load, frontside / Wind load, backside	5400Pa/2400Pa
Application Leve	Class A	Snow load, frontside / Wind load, backside	5400Pa/2400Pa
